Low-Profile Solenoid Lock with Supervisory Feedback

TLX Technologies introduces our newest innovation in solenoid locking mechanisms.

客户问题

This solenoid-actuated locking system provides a combination of several patent-pending features that make it especially attractive to OEMs with applications requiring locking mechanisms in a limited space. The low-profile of the mechanism mated with the relatively long stroke of the locking pin allows for flexibility in applications where space is limited but strong lockout load is essential.

TLX 解决方案

The unique design of the locking pin allows for an open door to be closed and locked without impacting the solenoid’s lock state. Designed as a latching, two-position solenoid, the mechanism requires power only to change states. A short pulse of reverse polarity to the solenoid will change the state of the lock. Supervisory feedback of the locking pin position has been integrated into this smart design. Scalable based on application requirements.

查看设计方案

Low-Profile Latching Solenoid Lock

Supply voltage: 13 Vdc

Locking pin stroke: 14 mm

Current draw: 1.5 amps max.

Locking pin diameter: 15 mm

Height: 40 mm

Width: 38 mm

Mounting bracket: 12 gauge steel

TLX提供的任何组件，均可根据客户的不同系统、技术参数等要求进行设计和定制。本网站上的示例仅供说明目的。

Working with TLX

Experienced partner of industry leaders, first-tier suppliers, and OEMs
Direct access to our design and engineering team
Localized production in USA and China
Dependable single-source solution from design to delivery
