Achieve Immediate Response in a Fault-Interrupting Device

These large latching solenoids with high latching force were designed for a manufacturer of high voltage power distribution equipment to disconnect power quickly to prevent equipment damage.

客户问题

A manufacturer of high voltage power distribution equipment needed to actuate a fault-interrupting device while switching functions in their high voltage equipment. This device would disconnect power if a fault could not be cleared immediately or maintenance needed to be performed.

In order to avoid equipment damage, the actuation solution needed to be durable with a high latching force to actuate immediately, allowing the power to disconnect quickly.

TLX 解决方案

We designed several large latching solenoids that have a high latching force ranging from 100-300 lbs. These heavy-duty solenoids used residual magnetism, not constant power, to hold the latched position. When the system detects a fault, a short pulse of power causes the solenoid to de-latch, activating the fault interrupter. Once maintenance is complete or the fault is cleared, another short pulse of opposite polarity causes the solenoid to re-latch. This solenoid is direct-acting and temperature stable with a fast response time.

查看设计方案

Large Latching Solenoid

Stroke: Up to 16.5 mm

Pull force: Up to 223 N

Latching force: Up to 1334 N

Supply voltage: 48 Vdc

Response times: <30 ms

Coil resistance at 20°C: 1.25 Ω

Transition velocity at switching: > 1 m/s

Durability: > 100K cycles

Momentary current pulse: Up to 40 A
